Auto Crane EC-2X Crane
+ Tap or click image to enlarge
EC-2X Manual Rotation And Extension
$6,488.80
$8,111.00
SKU 600900000
Product Details
EC-2X Manual Rotation And Extension Crane
Stowed Boom Length
5′ 8″ (1.73 m)
Extended Boom Length
9′ 3″ (2.74 m)
Width
1′ 7″ (.48 m)
Height
2′ (.6 m)
Base Plate Dimensions
16.0″ x 18.0″ (0.41 m x 0.45 m)
Single Line Speed
30 ft/min (9.17 m/min)
Motor
12 volt DC, series wound, 1.9 hp hoist motor
Cable
50 ft. (15.2 m) of ¼” (6 mm) aircraft quality cable
Truck must be equipped with jackleg extending minimum 3′ 3″ (1 m) from center-line of truck
8,000 GVWR minimum chassis requirement. (Does not include bodies and accessories)
Battery Information: 575 amp cold cranking rating, 130 minute reserve capacity, maintenance type battery required for 12 volt DC operation. 70 amp minimum truck alternator required
